Code printer is a non-contact ink-jet marking system controlled by single chip microcomputer.Through the control of the internal gear pump or the supply of compressed gas from the outside of the machine, to apply a certain pressure to the ink in the system, the ink through a nozzle dozens of micron aperture injection, respectively in different positions on the surface of the product, the formation of the required text, patterns and other marks.
Bottles Carton Pouch logo plastic bag batch number coding printing machine
Product Description
Bottles Carton Pouch logo plastic bag batch number coding printing machine
Quick Details
Warranty:1 Year
Packaging Material:Plastic
Packaging Type:Cartons
Type:Coding Machine
Condition:New
Automatic Grade:Automatic
Application:Boards, Pipe, Carton, Plastic
Driven Type:Electric
Voltage:14.8
Weight:5 kg
Certification:CE ROHS FCC
After-sales Service Provided:Video technical support, Overseas service center available
Product name: Expiry Date Inkjet Bottles Carton Pouch logo plastic bag batch number coding printing machine
Display:5″ high resolution display
Ink type:Water Based Ink, Quick Dry Ink
Ink consumption:15,000,000 characters in 3mm height
Print head:1 heads
Ink Color:Black, White, Red, Yellow, Blue, Green
Print speed:70 m/min
Print data:Variable batch, QR code, text, time, etc.
Keywords:inkjet date coder
Bottles Carton Pouch logo plastic bag batch number coding printing machine
| Shape features | Aluminium |
| Weight | 1.5kg |
| Dimension | 128*90*45mm |
| CPU | Quard core 1.4 GHz |
| Definition | 600PDI |
| Spray nozzle | Thermal foaming inkjet 2.5 |
| Printing direction | Adjustable with 360 degree, meet all kinds of production needs |
| Printing line | 1-8 lines (adjustable) |
| Printing height | 1.2mm-12.7mm |
| Printing distance | 1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm) |
| Printing content | Chinese, English, number, date, time, QR code, bar code, picture |
| Application | Board, carton, stone, pipe, cable, metal, plastic, electronics, automotive parts |
| Printing length | 2000characters for each message, no limitation on length |
| Printing speed | 70m/min |
| Ink type | Quick-dry environmental ink, water-based ink and oily ink |
| Ink color | black, white, red, blue, yellow, green, invisible |
| Ink volume | 42ml(usually can print 800,000 characters) |
| Interface | USB, RS232, DB15, Photoelectric interface, Bluetooth 4.0, Wi-Fi |
| Voltage | DC16.8 lithium battery |
| Storage | the system can store more than 1000 mass (external USB make the information transfer in a free way) |
| Working condition | Temperature:0 – 45 degree; Humidity: 10% – 80% |
Bottles Carton Pouch logo plastic bag batch number coding printing machine
FAQ
1. Can this printer print my product?
We have water-based ink cartridge and quick dry ink cartridge to suit different materials. Most of the products can be printed with EXP date, batch code, bar code, QR code, serial number, logo and other printing information.
2, How long will it take for the ink to become dry?
3-5 seconds.
3, Can you send me the video to show how the machine works?
Certainly, we have made videos of every machine and for different uses and upload to youtube, just see our channel meenjet.
4, How can I know your machine works well?
Before delivery, we have tested every machine and adjusted it to the best condition. If you have special production condition, we could also adjust the machine for you.
5. Do I only use the supplies of the machines from your factory?
Not necessarily. We offer original import ink supplies, but the machine could suit for most cartridges. You could choose other as your wish.
